What is the inside dimensions of a window opening in a wall of modular bricks with 3/8" mortar joints if the opening is 6-1/2 bricks wide and 29 courses high?What is the inside dimensions of a window opening in a wall of modular bricks with 3/8" mortar joints if the opening is 6-1/2 bricks wide and 29 courses high?
Question:
What is the inside dimensions of a window opening in a wall of modular bricks with 3/8" mortar joints if the opening is 6-1/2 bricks wide and 29 courses high?
What is the inside dimensions of a window opening in a wall of modular bricks with 3/8"
mortar joints if the opening is 6-1/2 bricks wide and 29 courses high?
This is AI generated Response.
Asked by: Md Israrul Haque
Created at: 2025-08-25 19:23:35
Asked by: Md Israrul Haque
Created at: 2025-08-25 19:23:35
Final Answer:
Rendered
Raw Text
Did you like this answer?
Let's solve the problem step by step.
### **Given:**
- **Brick type:** Modular brick
- **Mortar joint thickness:** 3/8"
- **Opening:** 6-1/2 bricks wide, 29 courses high
### **Modular Brick Size:**
Standard *modular brick* size is **3-5/8" x 2-1/4" x 7-5/8"** (Width x Height x Length).
When including a 3/8" mortar joint:
- **Nominal dimensions:** 4" x 2-2/3" x 8"
But let's use the actual brick size plus the joint for accuracy.
---
#### **Width Calculation (6-1/2 bricks wide):**
- Each brick (lengthwise) = 7-5/8"
- Each mortar joint = 3/8"
For 6-1/2 bricks, there are **6 full mortar joints** between bricks.
So,
- **Total width = (6.5 × brick length) + (6 × mortar joint thickness)**
- **Total width = (6.5 × 7-5/8") + (6 × 3/8")**
- **Total width = (6.5 × 7.625") + (6 × 0.375")**
- **Total width = 49.5625" + 2.25"**
- **Total width = 51.8125"**
---
#### **Height Calculation (29 courses high):**
- Each brick (height) = 2-1/4"
- Each mortar joint = 3/8"
For 29 courses, there are **28 mortar joints** between bricks.
- **Total height = (29 × brick height) + (28 × mortar joint thickness)**
- **Total height = (29 × 2.25") + (28 × 0.375")**
- **Total height = 65.25" + 10.5"**
- **Total height = 75.75"**
---
### **Final Answer:**
**The inside dimensions of the window opening are:**
- **Width:** 51-13/16" (or 51.8125")
- **Height:** 75-3/4" (or 75.75")
Let me know if you need these in feet and inches!
