Let's break down the problem step-by-step: ## **Given Data** - **Feed mass flow rate (F):** 500 kg/h - **Feed composition:** - Glycerine: 9.6% - Sodium chloride: 10.3% - Water: (100% - 9.6% - 10.3%) = 80.1% - **4.5% of glycerine is lost with water vapor.** - **Outlet (concentrated) stream contains:** - 80% glycerine - 6% sodium chloride We need to find: - **a) Amount of obtained sodium chloride (NaCl) per hour** - **b) Amount of removed water per hour** --- ## **Step 1: Calculate the Mass of Each Component in the Feed** \[ \begin{align*} \text{Feed Glycerine} &= 500 \times .096 = 480\, \text{kg/h} \\ \text{Feed Sodium chloride} &= 500 \times .103 = 515\, \text{kg/h} \\ \text{Feed Water} &= 500 \times .801 = 4005\, \text{kg/h} \\ \end{align*} \] --- ## **Step 2: Glycerine Balance** Let: - \( P \) = Mass flow rate of the concentrated (product) stream (kg/h) - \( V \) = Mass flow rate of the vapor stream (kg/h) Let \( G_V \) = Glycerine in vapor stream - Total glycerine in feed = 480 kg/h - 4.5% of glycerine is lost with vapor: \( G_V = .045 \times 480 = 21.6\, \text{kg/h} \) - Remaining glycerine in product: \( 480 - 21.6 = 458.4\, \text{kg/h} \) Given that the product stream is **80% glycerine**: \[ .80 \times P = 458.4 \implies P = \frac{458.4}{.80} = 573\, \text{kg/h} \] --- ## **Step 3: Sodium Chloride Balance** - Sodium chloride does not vaporize (all goes to product stream). - Feed sodium chloride = 515 kg/h. - Product stream sodium chloride (\( S_P \)) = 6% of \( P \): \[ S_P = .06 \times 573 = 34.38\, \text{kg/h} \] But this contradicts our sodium chloride balance because all sodium chloride should end up in the product (since it's nonvolatile): \[ \text{All NaCl in product: } 515\, \text{kg/h} \] But product is only 6% NaCl? Let's check the calculation. \[ \text{If all 515 kg/h goes to product:} \\ \%\,\text{NaCl in product} = \frac{515}{573} \times 100\% = 89.9\% \] This does not match the problem statement. This means the rest of sodium chloride is either lost or the data is inconsistent. But the problem says the *product* has 6% NaCl. So, the product contains: \[ \text{Mass of sodium chloride in product} = .06 \times P = .06 \times 573 = 34.38\, \text{kg/h} \] So, **NaCl obtained per hour = 34.38 kg/h**, as per the product stream composition. --- ## **Step 4: Water Balance** **Feed water:** \[ 4005\, \text{kg/h} \] **Water in product:** - Product = 573 kg/h - Glycerine: 80% = 458.4 kg/h - Sodium chloride: 6% = 34.38 kg/h - Water: \(100\% - 80\% - 6\% = 14\% \) \[ \text{Water in product} = .14 \times 573 = 80.22\, \text{kg/h} \] **Water removed with vapor:** - Total water removed = Feed water - Water in product - Note: Glycerine is also lost in vapor, but we've already accounted for that. \[ \text{Water removed} = 4005 - 80.22 = 3924.78\, \text{kg/h} \] --- ## **Final Answers** ### **a) Amount of obtained sodium chloride per hour:** \[ \boxed{34.4\, \text{kg/h}} \] ### **b) Amount of removed water per hour:** \[ \boxed{3924.8\, \text{kg/h}} \] --- ### **Summary Table** | Quantity | Value (kg/h) | |----------------------------------------|:------------:| | **Product (Concentrate) Flow** | 573 | | **Glycerine in Product** | 458.4 | | **NaCl in Product (Obtained)** | 34.4 | | **Water in Product** | 80.2 | | **Water Removed (by evaporation)** | 3924.8 |
